Flexible Back Stretcher trainer GYX-L19A Company

Specification:

Gyx-l19a flexible training device

【Specification】: 1306 × 322 × 577mm

[Scope of safe use]: 4400 × 3400 (mm)

[How to use]: Users are sitting on the seat plate, their feet are placed on the pedal under the equipment, their legs are straightened, their abdomen is tightened, their upper body is naturally straight, her arms are together, and their hands are stretched forward. The scaled table above the training device is performed for physical flexion and extension exercises.

[Main function]: Exercise the flexibility of the body, improve the flexibility of the whole body and coordinate the coordination ability, enhance the muscle tension of the waist and back, and improve the strength and flexibility of the waist, back, and abdominal muscles.

【The main technical parameters】:

◆ Direct burial, the main stood pillars, and the seat columns adopt a national standard steel pipe with a diameter of 88mm and a wall thickness of 3mm;

◆ The beam adopts a national standard steel pipe with a specification of 20*30mm and a wall thickness of 2mm.

◆ At the top of the column, the discs are 100mm in diameter, and the wall thickness 6mm steel plate is connected to the support pipe. The support pipe uses a specification of 25*25*2mm national standard steel pipe, so that the spacing of the top and panel of the top of the column is greater than 30mm, which meets the national standard requirements;

◆ The chair is stamped with a cold plate with a thickness of 4mm. The chamfers of the periphery are R2.

◆ The board surface is corroded with full stainless steel, 1mm thick, and the talked tumbling with the human body is R2mm.

◆ Equipment nameplate is integrated with plate surface corrosion, which is convenient for users to view. The QR code logo is corroded with full stainless steel, with a size of 90*60 and a wall thickness of 0.8mm.

◆ The equipment is tested in accordance with the GB19272-2011 standard, and stability tests are tested, and the standard requirements are met.

◆ There is no hook, no crushing point, no shear point, no card clip, the gap between the pores and diameters of each place meets the GB19272-2011 standard;

◆ The equipment has a 1 -stop movement, which can be used only 1 person;

◆ Equipment columns are buried in depth of not less than 400mm, and the size of the ground is not less than 400*400*500mm;

◆ The equipment adopts a fully automatic CNC sawing bed, which is highly efficient and accurate. Skinidity treatment is performed before the equipment is welded to ensure that the surface of the workpiece has no oil and pollution. Follow and equip the dust collection and treatment system to purify the air of the workshop to ensure the health of the workers. The surface treatment uses the shot shot shot, which is thoroughly removed, the surface area of the workpiece is increased, and the plastic powder attachment is enhanced. Imported electrostatic spraying equipment, uniform powder out, strong powder adhesion, plastic surface resistance, dampness and heat, anti -aging, corrosion resistance, beautiful appearance, suitable for humidity and acid rain environment. The cyclone centrifugal powder pink recovery system can reach 98.6%, saving powder to reduce dust pollution, convenient operation, energy saving and environmental protection;

◆ Equipment packaging is the internal thickened air bubble film entangled, and the external packaging with two -layer packaging with wrapped wrapped, which effectively blocks bumps in the transportation to cause the equipment to be intact.
