Push up and dip station GYX-L25B Factory

Specification:

GYX-L25B arm support training device

[Specification]: 1925x567x1450 (mm)

[Scope of safe use]: 5000x3600 (mm)

[How to use]: The practitioner holds the horizontal pole with both hands, jumps up to support his arms, then bend his arms at the same time, straighten his legs, so that the bar surface can reach the chest position, and then the arms are quickly straightened (hold the horizontal hand tightly with both hands. Polar, prevent falling), repeat exercise.

[Main functions]: Enhance the muscle strength of the upper limbs, chest and shoulders, especially enhanced the strength of the bougainvillea, biceps and triceps, and improve the supporting power of the upper limbs and wrist muscles and the bearing capacity of the upper limb bone. Improve the coordination of human movement and the ability to coordinate the whole body.

【The main technical parameters】:

◆ Direct buried type, the main column adopts a national standard steel pipe with a diameter of 114mm and a wall thickness of 3mm;

◆ The handrail curved is a national standard steel pipe with a diameter of 42mm and a thickness of 3mm. The left and right center of the two armrests is 510mm. It meets the requirements of human movement. One side armrest pipe is 1360mm from the ground, and the other side is 1210mm from the ground.

◆ The nameplate of the equipment is corroded with full stainless steel, with a size of 220*80mm, sturdy rivets, and the edges are close to the column to avoid causing hook damage;

◆ The equipment is tested in accordance with the GB19272-2011 standard, and stability tests are tested, and the standard requirements are met.

◆ There is no hook, no crushing point, no shear point, no card clip, the gap between the pores and diameters of each place meets the GB19272-2011 standard;

◆ The thickness of the buffer layer is 200mm to avoid accidental damage to users;

◆ The size of the land is not less than 500*500*800mm;

◆ The equipment uses a fully automatic CNC sawing bed, which is highly efficient and accurate. The bending process uses a CNC bending machine. The angle is accurate and beautiful. Mixed gas welding, beautiful welding shape, straight welding tract, no need to polish, and equipped with dust collection and treatment systems, purify the air of the workshop, ensure the health of workers, the surface treatment uses the throwing process, thorough rust removal, increase the surface area of the workpiece, enhance the enhancement Plastic powder adhesion, outer surface of the Forbidden City Green Environmental Protection Static Powder, using imported static spraying equipment, uniform powder, strong powder adhesion, plastic surface resistance, dampness and heat, anti -aging, corrosion resistance, beautiful appearance, suitable for humidity and sour rain Environment, the coating formula of the product does not contain toxic elements. Powder recovery uses a whirlwind centrifugal machine powder recovery system.

◆ Equipment packaging is the internal thickened air bubble film entangled, and the external packaging with two -layer packaging with wrapped wrapped, which effectively blocks bumps in the transportation to cause the equipment to be intact.
