Reclining Exercise Bike GYX-L34A Supplier China

Specification:

GYX-L34A Reclining Exercise Bike

[Specification]: 1135 × 600 × 986 (mm)

[Scope of safe use]: 4200 × 3600 (mm)

[How to use]: Hold your hands on the left and right armrests on the seat plate, the pedal pedal turns back, and the upper limbs will be coordinated to coordinate the movement. The pedal pedal should be used to drive the upper foot exercise, and it should not be too fast.

[Main functions]: Through the whole body coordination exercise, it can significantly strengthen the heart and lung function and relieve fatigue.

【The main technical parameters】:

◆ The embedded type, the main column adopts a national standard steel pipe with a diameter of 114mm and a wall thickness of 3mm;

◆ The national standard steel pipes with a diameter of 60mm and a wall thickness of 3mm are mainly carried on the beam.

◆ The handrail adopts a national standard steel pipe with a diameter of 32mm and a wall thickness of 2.5mm. The arm of the arm is a national standard steel pipe with a specification of 25mm*50mm and a wall thickness of 2.5mm.

◆ Use a cold plate with a thickness of 4mm in a cold plate for molding, and the chamfer of the peripheral R2 to avoid scratching danger;

◆ The diameter of the shaft is 25mm, 2 6205 high -quality bearing, the pedal shaft diameter is 15mm, and the bearing is 4 6002 high -quality bearing;

◆ Internal use of two bearing to increase the damping structure of nylon -resistant nylon in the intermediate, control the rotation speed of the turntable to ensure the personal safety of the user, and to ensure the use requirements;

◆ The handlebar is made of vulcanized rubber, which is good for anti -aging. There are also anti -theft measures to be safe and durable;

◆ The nameplate of the equipment is corroded with full stainless steel, with a size of 220*80mm, sturdy rivets, and the edges are close to the column to avoid causing hook damage;

◆ The equipment is tested in accordance with the GB19272-2011 standard, and stability tests are tested, and the standard requirements are met.

◆ There is no hook, no crushing point, no shear point, no card clip, the gap between the pores and diameters of each place meets the GB19272-2011 standard;

◆ The depth of the equipment is not less than 500mm, and the size of the embedded size is not less than 500*500*600mm;

◆ The equipment uses a fully automatic CNC sawing bed, which is highly efficient and accurate. The bending process uses a CNC bending machine. The angle is accurate and beautiful. Mixed gas welding, beautiful welding shape, straight welding tract, no need to polish, and equipped with dust collection and treatment systems, purify the air of the workshop, ensure the health of workers, the surface treatment uses the throwing process, thorough rust removal, increase the surface area of the workpiece, enhance the enhancement Plastic powder adhesion, outer surface of the Forbidden City Green Environmental Protection Static Powder, using imported static spraying equipment, uniform powder, strong powder adhesion, plastic surface resistance, dampness and heat, anti -aging, corrosion resistance, beautiful appearance, suitable for humidity and sour rain Environment, the coating formula of the product does not contain toxic elements. Powder recovery uses a whirlwind centrifugal machine powder recovery system.

◆ Equipment packaging is the internal thickened air bubble film entangled, and the external packaging with two -layer packaging with wrapped wrapped, which effectively blocks bumps in the transportation to cause the equipment to be intact.
