Waist and Neck Massager GYX-L37 Factory

Specification:

GYX-L37 Waist and Neck Massager

[Specification]: 1939 × 753 × 1319 (mm)

[Scope of safe use]: 5000 × 3800 (mm)

[How to use]: The user is sitting on the seat, the neck is close to the massage stick, holding the handle with both hands, and slowly moved up and down to massage the neck muscles; the user is sitting on the seat, holding the handrail, the waist is close to Massage stick, slowly move the handrail up and down, massage waist muscles, and repeatedly exercise.

[Main function]: Relax the muscles of the user's neck and waist, which can effectively eliminate waist and back and neck muscle fatigue, regulate the nervous system, improve the blood circulation of the user's waist, can clear the meridians, make the air flow unblocked, and adjust the function of the relevant viscera.

【The main technical parameters】:

◆ Straight buried, the main pillars adopt a national standard steel pipe with a diameter of 114mm and a wall thickness of 3mm;

◆ Limit the three -sided impact internal limit of full casting steel, increase the area of force, and use polyurethane materials for impact pads. , Limit the thickness of the side board is 10mm, the diameter of the limited level is 133mm, the length is 80mm, and the thickness is 8mm.

◆ The handrail is used to use tube retractable technology, which shrinks the pipe with a diameter of 42mm to 32mm in diameter in order to install the handle. This method is good in overall, beautiful in appearance, convenient processing, and durable;

◆ Cold plates with diameter 300mm, 22mm height, and 4mm with diameter are stamped, and the head chamfers are used to avoid danger of scratching. The national standard steel pipe with a diameter of 48mm and a diameter of 32mm is 2.5mm.

◆ The whole machine bearing waterproof ring adopts a special skeleton oil seal waterproof ring. It has good closedability, waterproof and dustproof, and durable;

◆ The waist massage wheel is made of nylon alloy, anti -aging, high and low temperature, comfortable massage effect, safe and durable, the diameter of the shaft is 25mm, and 4 6205 high -quality bearings are used;

◆ The neck massage stick is made of nylon, which is designed according to the structure of the human neck, and the surface hardness is moderate, which meets the requirements of human massage;

◆ The handlebar is made of vulcanized rubber, which is good for anti -aging. There are also anti -theft measures to be safe and durable;

◆ The top of the column is closed, and the buckle is stamped with a 2mm thick steel plate. There is a Gui Yuxing logo on the top to avoid entering the rain;

◆ The nameplate of the equipment is corroded with full stainless steel, the size is 220*80mm, the pull rivets are strong, and the edges are close to the column.

Avoid hook damage;

◆ The equipment is tested in accordance with the GB19272-2011 standard, and stability tests are tested, and the standard requirements are met.

◆ There is no hook, no crushing point, no shear point, no card clip, the gap between the pores and diameters of each place meets the GB19272-2011 standard;

◆ The equipment has 2 movements, and only 2 people can be used at the same time;

◆ Equipment columns are buried in depth of not less than 500mm, and the size of the ground is not less than 500*500*600mm;

◆ The equipment uses a fully automatic CNC sawing bed, which is highly efficient and accurate. The bending process uses a CNC bending machine. The angle is accurate and beautiful. Mixed gas welding, beautiful welding shape, straight welding tract, no need to polish, and equipped with dust collection and treatment systems, purify the air of the workshop, ensure the health of workers, the surface treatment uses the throwing process, thorough rust removal, increase the surface area of the workpiece, enhance the enhancement Plastic powder adhesion, outer surface of the Forbidden City Green Environmental Protection Static Powder, using imported static spraying equipment, uniform powder, strong powder adhesion, plastic surface resistance, dampness and heat, anti -aging, corrosion resistance, beautiful appearance, suitable for humidity and sour rain Environment, the coating formula of the product does not contain toxic elements. Powder recovery uses a whirlwind centrifugal machine powder recovery system.

◆ Equipment packaging is the internal thickened air bubble film entangled, and the external packaging with two -layer packaging with wrapped wrapped, which effectively blocks bumps in the transportation to cause the equipment to be intact.
